Description
BETTER TREATMENT OUTCOMES
Provides symptomatic relief of acute and chronic pain associated with musculoskeletal conditions and the management of post-operative pain1
Improved ultrasound coupling detection and monitoring ensures the patient is receieving the intended energy for their treatment.
Chattanooga’s proprietary VMS waveform achieves stronger muscle contractions and less neural fatigue while still providing a more comfortable experience for the patient.
Dual Frequency Ultrasound 1MHz or 3.3 MHz capability with 2cm2, 5cm2 and 10cm2 applicator options.
VERSATILE: QUICK SETUP AND IMPROVED PORTABILITY
Quick Treatment setup and customization
Improved Portability – Ergonomically designed device handle, lightweight design and optional long lasting battery makes it easy to treat patients wherever is required within the facility.
Reduced Complexity – Device Setup: Optional cart with large storage drawers ensuring all accessories are conveniently located close to the device. Magnetic fixation of the device to the cart allows for secure attachment without the need for any tools.
WAVEFORMS
VMS
Interferential Current (Traditional IFC, 4-pole)
Premodulated IFC (2-pole)
High Voltage Pulsed Current
Microcurrent
Asymmetrical Biphasic current – TENS
Symmetrical Biphasic current – TENS
Galvanic
Galvanic Interrupted
Monophasic Triangular Pulsed
Monophasic Rectangular Pulsed
Träbert
Russian
Diadynamic LP, MF, DF, Cpid/Cpiso
TECHNICAL DATA
Mains Power : 100-240 VAC, 50/60 Hz, 1.0 A
Weight : 2.2 kg (4.9 lbs)
Shipping Weight: 3.9 kg (8.5 lbs)
Dimensions: 34.6 cm x 25 cm x 12 cm (13.6″L x 9.8″W x 4.7″H)
Electrical Safety Class: Class 1, Electrotherapy Type BF, Ultrasound Type B
Safety Tests: IEC 60601-1, ISO 10993-1, IEC 60601-2-5, IEC 60601-1-2, IEC 60601-2-10,
IEC 60601-1-6, IEC 62366-1, IEC 62304, IEC 62133, ISO 14971
MODEL NO. 4778
